AutoCAD® Training

Why Penn Foster Career School?

  • Regionally & Nationally Accredited
  • Self-Paced
  • Supportive
  • Low monthly payments

Program Overview

Develop your technical abilities and talent for drafting with Penn Foster Career School’s online Drafting with AutoCAD® Program. In our online training courses, you can train at home and at a pace that’s right for you. Discover basic sketching techniques, and learn the mathematical skills necessary to the task of drafting. Create drawings for structural, civil, electrical, and electronic schematic drafting with AutoCAD software.

You can complete this program in as little as five months. People who complete AutoCAD training can be found working in a variety of areas, such as an engineering firm, government agency, automotive company or dealership, construction, landscaping, or patenting company.

Curriculum Details

Program Goal and Outcomes

Program Goal

The program provides students with the necessary skills for entry into the field of drafting. Upon completion of the course, students will be able to create mechanical and architectural drawings, both by hand and using AutoCAD software.

Program Outcomes

Upon completion of the program, students will be able to:

  • Be familiar with the basic techniques used in sketching and with occupations that use drafting language
  • Complete drawings using orthographic projection, points of view, and shape descriptions
  • Know the techniques of lettering, and recognize the lines used in mechanical and architectural drawings as well as the representation of math operations in drafting
  • Understand the use of drafting vocabulary, geometry, and instruments in the layout of drafting problems and geometric designs
  • Describe size and shape using the regular views of drafting and the principal views of orthographic projection
  • Work with various views, projections, tolerancing techniques, dimensions, and control frames
  • Complete working drawings and become familiar with the capabilities, applications, and development of computer software drawing programs
  • Understand the capabilities, applications, and development of AutoCAD and use it to draw basic objects using lines, circles, and arcs
  • Become proficient with the advanced applications of the software including plotting/printing, drawing file storage and sharing, software personalization, and basic 3D modeling.
  • Prepare an AutoCAD drawing representing a plat map of a subdivision, using blocks, layers, linetypes, and annotations
  • Prepare complete sets of architectural and civil drawings for a site plan, transit lines, and plans and profiles from survey information
  • Prepare complete HVAC drawings, electrical diagrams and cable assemblies, industrial electrical schematics, and electronic block and schematic diagrams
